Mounting Kits
Mounting Kits
FEATURES
? Pre-packaged in heat-sealed plastic bags for use on assembly line.
? Stock mounting hardware using one number
for better control and identification.
? Three different insulating materials available:
Low cost Thermalfilm TM
High temperature Mica
High performance Thermalsil TM lll
? Other insulator materials available for special order include:
hard anodized aluminum and aluminum oxide.
? Individually packaged for convenient stocking and handling
of mounting hardware. Kits contain all hardware necessary to
electrically isolate the transistor from the heat sink.
TO-220 Mounting kit part number 4880
ORDERING INFORMATION
Part number
4880G
Description
Kit with Thermalfilm TM
Kit with Thermalsil III
4880MG
4880SG
Kit with Mica Insulator
TM
5
TRANSISTOR
NOT INCLUDED
2
EACH KIT INCLUDES:
Part number
Item
Qty
Description
43-77-9
(56-77-9)
(53-77-9)
1
1
Insulator
Thermalfilm TM (see page 101)
Mica (see page 103)
Thermalsil TM III (see page 103)
3
1
7721-7PPS
MS15795-804
2
3
1
1
Shoulder washer
Flat washer #4
6
4
No. 4-40 UNC-2B
MS35649-244
4
1
Hex nut
No. 4-40 UNC-2A X
MS51957-17
MS35338-135
5
6
1
1
1/2 Long phillips pan head screw
Lock washer, No. 4
Note: Smooth side of flat washer should be placed against insulator when using the kit.
TO-3 Mounting kit part number 4804
ORDERING INFORMATION
Part number
Description
4804G
Kit with Thermalfilm TM
TRANSISTOR
4804MG
4804SG
Kit with Mica Insulator
Kit with Thermalsil TM III
5
NOT INCLUDED
EACH KIT INCLUDES:
Part number
Item
1
Qty
1
Description
Insulator
1
43-03-2
(56-03-2)
(53-03-2)
7721-5PPS
MS15795-805
MS35649-264
2
3
4
2
2
2
Thermalfilm TM (see page 101)
Mica (see page 103)
Thermalsil TM III (see page 103)
Shoulder washer
Flat washer #6
No. 6-32 UNC-2B
2
7
4
3
6
Hex nut
MS 51957-30
5
2
No. 6-32 UNC-2A X
1/2 Long phillips pan head screw
MS35338-136
322-156
6
7
2
1
Lock washer, No. 6
Solder lug
Note: Smooth side of flat washer should be placed against insulator when using the kit.
AMERICA
USA Tel: +1 (603) 224-9988 email: info@aavid.com
ASIA
Singapore Tel: +65 6362 8388 email: sales@aavid.com.sg
www.aavidthermalloy.com
EUROPE
Italy Tel: +39 051 764011 email: sales.it@aavid.com
United Kingdom Tel: +44 1793 401400 email: sales.uk@aavid.com
Taiwan Tel: +886 (2) 2698-9888 email: sales@aavid.com.tw
99
